Arc spray molding technology is an efficient and cost-effective method for creating molds, especially suitable for rapid prototyping and small-batch production. The process involves using two metallic wires as consumable electrodes, which are melted by an electric arc formed between the wire ends. The molten metal is atomized into fine droplets with compressed air and accelerated at high speed onto a substrate, forming a metal coating. This metal coating acts as the cavity surface for the mold, which is reinforced with a backing material and a steel structure to create a quick and economical mold.

The arc spray molding process can be divided into five main steps:

1. Model Preparation

The mold can be made from a variety of materials such as wood, plastic, gypsum, or rubber. The most critical step in model preparation is the application of a release agent. The release agent serves two key purposes:

• It helps the metal particles adhere to the substrate, ensuring that the sprayed metal stays firmly in place.
• It prevents overheating, damage, or deformation of the model, acting as both a heat insulator and a release agent.

The release agent should be applied evenly on the model’s surface and allowed to dry to form a protective film before proceeding.

2. Metal Spraying

Once the release agent has dried, the model is ready for metal spraying. The spraying process is carried out under optimal parameters to ensure a continuous, even coating. The spray gun should move steadily to avoid overheating or distortion of the coating. The typical coating thickness is around 2-3mm, though this can vary depending on the specific requirements of the mold.

3. Creating the Mold Framework

If the mold is intended to withstand internal pressure or be mounted on a molding machine, it is essential to construct a framework for the mold. This framework should be reinforced and made with appropriate fillers. Two critical points to consider when constructing the mold framework are:

• The thermal expansion properties of the framework material should match those of the metal coating and the fillers.
• The dimensions of the framework and the positioning of the injection ports must be customized based on the specifications of the molding machine to be used.

4. Pouring the Mold Fill Material

During the production of plastic products, it is essential that the mold has good thermal conductivity and heat dissipation capabilities. Therefore, the choice of pouring material should prioritize high thermal conductivity and low solidification shrinkage rates. The fill material should also possess high compressive strength and wear resistance, as the mold will operate under certain temperatures and pressures.

A typical fill material consists of epoxy resin mixed with metallic powders such as aluminum powder or aluminum particles. The epoxy resin provides a strong bond between the coating and the mold framework, while the metallic powders enhance the thermal conductivity of the mold. To improve wear resistance, iron powder can also be added to the filler. Additionally, cooling tubes can be placed inside the mold during the pouring process to improve heat dissipation.

5. Demolding and Post-processing

Once the mold has been filled and the fill material has solidified, the mold is ready to be demolded. If the preparation steps were done correctly, demolding should not be difficult. The release agent residue left on the metal coating must be carefully cleaned to ensure the surface quality of the mold.

After demolding, further post-processing steps, such as polishing or surface finishing, can be carried out to meet the specific requirements of the mold. These final steps ensure that the mold has a smooth, defect-free surface ready for production.

Summary of the Process

The arc spray molding process can be summarized in the following steps:

1. Model Preparation: Apply a release agent on the model’s surface.
2. Metal Spraying: Spray metal onto the model to form the mold cavity.
3. Mold Framework Creation: Construct a supporting framework if necessary, ensuring compatibility with the mold and machine.
4. Fill Material Pouring: Pour a high-conductivity filler material into the mold to reinforce the coating and improve heat dissipation.
5. Demolding and Post-processing: Remove the mold from the model, clean it, and perform any necessary finishing steps.

This method offers a fast, economical, and versatile solution for quick mold manufacturing, especially suited for applications requiring rapid prototyping, small-batch production, and frequent design iterations. The use of arc spray molding allows manufacturers to reduce production time and costs while maintaining the flexibility to quickly adapt to changing market demands.
